Shrink fit chucks / HSK-A 80 / d2 20.000 mm /  Lg=160.000 mm / DIN 69882-8

  • Connection code machine side: HSK-A
    Connection code machine side: HSK-A
    Connection code machine side: HSK-A
  • Standard: DIN 69882-8
    Standard: DIN 69882-8
    Standard: DIN 69882-8
  • Surface: bright
    Surface: bright
    Surface: bright
SKU
4736 120.080
EAN
4031093705257
To see prices, please log in. New customers can create a user account HERE or add the desired products to the shopping cart and then send a request for quotation.
Shrink fit chucks / HSK-A 80 / d2 20.000 mm /  Lg=160.000 mm / DIN 69882-8
Shrink fit chucks / HSK-A 80 / d2 20.000 mm / # 4736 / M16 x 1 / DIN 69882-8 / bright / Execution: HSK-A according to ISO 12164-1 / DIN 69893-1 • dimensions according to DIN 69882-8 • balancing quality: G 2.5 / 25,000 rpm
or rev. < 1 gmm • for tool shanks d1 h6 • axial length adjustment • balancing thread 4xM6/6xM6 • concentricity < 3 μm
l1 from 120 mm = 4 μm
l1 from 160 mm = 5 μm
l1 from 200 mm = 7 μm
Connection code machine side
HSK-A
Norm
DIN 69882-8
Surface
bright
Discount group
148
Type
4736
Code no.
120.080
Weight
2.240
Nominal dimension thread
M16 x 1
External Ø
80.000
Shank length
40.000
Holder, machine side
HSK-A 80
Reach length
160.000
Internal Ø
20.000
Radius
1.000
Width
26.000
Setting length
51.000
Setting range length
10.000
Offset Ø 2
42.000
Intersection Ø
33.000
Statistical goods number
84661038
    Shrink fit chucks / Catalogue-No.: 4736
